Wavelength (nm)

320±1

Output power (mW)

>1, 2, 3, …, 20

Transverse mode

Near TEM₀₀

Operating mode

CW

Power stability (rms, over 4 hours)

<10%

Warm-up time (minutes)

<10

M² factor

<2.0

Beam divergence, full angle (mrad)

<2.5

Beam diameter at the aperture (mm)

~1.5

Beam height from base plate (mm)

45

Polarization ratio

>50:1 (Horizontal)

Operating temperature (℃)

10~35

Spectral purity

>99%

Power supply (90-264VAC)

PSU-H-FDA

Expected lifetime (hours)

5000

Datasheet
