HS1/ 5+TP100


Laser Power Meter




Features:
  • Wavelength range: 0.19 -15µm
  • Damage threshold: 1.5KW/cm2
  • Power measurement range: 100µW-5W
  • Active Area diameter: 9mm
  • SMA905/ FC fiber switch connector (Optional)
  • Support downlodad for Power Meter

Header Model TP100
Probe Model HS1 HS5
Power Range 100µW - 1 W 500µW - 5 W
Active Area Diameter 9 mm 9 mm
Probe Coating Film Broadband coating
Probe Material Thermopile
Wavelength Range 0.19-15 μm
Max. Average Power Density 1.5 kW/cm2
Sensitivity 100µW 500µW
Calibration Uncertainty (k=2) ±2%
Response Time (0-90%) <1 sec.
Linearity ±0.5%
Power Supply 18650 (2 batteries)
Overall Weight 1.434 kg
Cooling Method Air cooling
Computer Interface USB 1.1 and  USB 2.0
Instrument Power 100-240 VAC, 50/60 Hz, DC 12V-3.34A
Temperature (Operating) 5°C - 45°C (41°F - 113°F)
Temperature (Storage) -20°C - 70°C (-4°F - 158°F)
Warranty Period 1 year
Datasheet

Header TP100 Probe HS1/ 5
