Header Model |
LP100 |
|
Probe Model |
TS100 |
|
Power Range |
100 mW - 100 W |
|
Max. Power
Measuring Time |
<3 min |
|
Sensitive
Diameter |
25 mm |
|
Detector Coating |
Broadband |
|
Detector Element |
Thermopile |
|
Wavelength Range |
0.19-20 μm |
|
Max. Average
Power Density |
36 kW/cm2 |
|
Sensitivity |
100 mW |
|
Calibration
Uncertainty(k=2) |
±2% |
|
NEP (Noise
Equivalent Power) |
1 mW |
|
Response Time
(0-90%) |
<1 sec. |
|
Linearity |
±1% |
|
Total Weight |
2.94 kg |
|
Cooling Method |
Fan-cooled |
|
Computer
Connecter |
USB 1.1 and
USB 2.0 |
|
Instrument Power |
100-240 VAC,
50/60 Hz, DC 12V-3.34A |
|
Temperature
(Operating) |
5°C - 45°C
(41°F - 113°F) |
|
Temperature
(Storage) |
-20°C - 70°C
(-4°F - 158°F) |
